Octagonal Steel Electrical Power Pole 10m Galvanized Steel Pole AWS D 1.1

one 40HQ
MOQ
Anlaşılabilir
fiyat
Octagonal Steel Electrical Power Pole 10m Galvanized Steel Pole AWS D 1.1
Özellikleri Fotoğraf Galerisi Ürün Açıklaması Fiyat talebi
Özellikleri
Teknik Özellikler
tip: düz kutup, çekme direği, dönüş direği
stil: galvanizleme
Rüzgar hızı: 160km / s, 30m / s
Dimenstion torlance: + -% 2
İçin uygun: Elektrik dağıtımı
Kaynak standardı: AWS D 1.1
Vurgulamak:

10m galvanizli çelik direk

,

galvanizli çelik direk 10m

,

gi sekizgen ışık direği

Temel bilgiler
Place of Origin: China
Marka adı: Milky Way
Sertifika: ISO//BV
Model Number: 10m Galvanized Octagonal Steel Electrical Power Pole Price Types
Ödeme & teslimat koşulları
Packaging Details: as per customer request
Delivery Time: usually 2 weeks after confirming
Payment Terms: T/T
Supply Ability: 300 pieces pole per day
Ürün Açıklaması

10m Galvanized Octagonal Steel Electrical Power Pole Price Types



Material:

Hot rolled steel, Q235,Q345,S235, or customized

Pole’s height

3m –15m

length

Within 16m once forming without slip joint

Wall thickness

2.5mm-20mm or optional

Pole's Shape:

Round, Polygonal, Octagonal, Conial

Arm type:

Single arm, Double arm, or as per cliens' request

Application:

road,avenue, street, expressway, park, square

Temperature range

-35 °C~+45 °C

Max wind velocity

Aganist wind pressure of 160Km/h

Base plate mounted

Base plate is square, octagonal or round in shape with slotted holes for anchor bolt and dimension as per customer’s requirement.

Ground mounted

The length buried underground as per customer’s requirement.



Octagonal Steel Electrical Power Pole 10m Galvanized Steel Pole AWS D 1.1 0

Electric Power Tower includes angle steel tower, tapered tubular steel, transformer substation framework, power plant framework and so on.

Electric power tower is the steel structure frame of bracing electrical wires, keeping a sage distance of guild wires and buildings on the ground. According to appearance, the power tower can be divided to glass type tower, cat head type tower, Shang type tower, Gan type tower and doliform tower. On the basis of application, power tower can be separated to tension type tower, linear type tower, angle type tower, transposition type tower, terminal type power tower and crossing type power tower. The design feature of all tower is space truss structure, forming by single equilateral angle steel, making of material of Q235 (A3F) and Q345 (16Mn) and using black bolt of shearing force to connect pole parts. The tower is mainly consists of angle steel, connecting steel plate and bolt, some is component part of steel plate welding, as column foot. The simple tower part making the hot zincification anticorrosion, transportation, construction and erection is much easy. Usually use shackles on main pole of tower which the height is less than 60 meters for convenience of workers to ascend.



Octagonal Steel Electrical Power Pole 10m Galvanized Steel Pole AWS D 1.1 1



Steel tube tower mainly use between high voltage transmission lines, with lightning rod hanging place on top, bolt connecting tower body with cross arm which has wires hanging place. The intersecting surface of tower is oblong, and the intersection surface macroaxis of tower and cross arm is 0 to 90 degree angle. In practical application, raw material can be saved of shorten the circumference of intersection surface by bearing the max bending moment of oblong intersection surface macroaxis.



Octagonal Steel Electrical Power Pole 10m Galvanized Steel Pole AWS D 1.1 2
