Gr65 Material Steel Power Pole with 460 MPa Yield Strength and 620 MPa Tensile Strength for High Voltage Transmission

1 adet
MOQ
Anlaşılabilir
fiyat
Gr65 Material Steel Power Pole with 460 MPa Yield Strength and 620 MPa Tensile Strength for High Voltage Transmission
Özellikleri Fotoğraf Galerisi Ürün Açıklaması Fiyat talebi
Özellikleri
Teknik Özellikler
Ürün adı: Çelik Güç Direği
Uygulama: Güç dağıtımı
Malzeme: Gr65
Minimum akma dayanımı: 460 mpa
Maksimum nihai çekme mukavemeti: 620 mpa
Duvar kalınlığı: 1mm-36mm
Vurgulamak:

Gr65 Material Steel Power Pole

,

460 MPa Yield Strength Electric Transmission Pole

,

620 MPa Tensile Strength Galvanized Steel Pole
Temel bilgiler
Menşe yeri: ÇİN
Marka adı: MilkyWay
Sertifika: ISO9001/BV/
Model numarası: Çelik Güç Direği
Ödeme & teslimat koşulları
Ambalaj bilgileri: Müşteri isteği olarak
Teslim süresi: Ödemenizi aldıktan sonra 20 iş günü
Ödeme koşulları: T/T, L/C Sight
Yetenek temini: günde 300 adet
Ürün Açıklaması
35FT 70FT 90FT Bitumen Coated Steel Power Pole for High Voltage Power Transmission Line
Product Specifications
Types Length 45ft (13.75m) 50ft (15.25m) 55ft (16.80m) 60ft (18.30m) 65ft (19.85m) 70ft (21.35m)
B (0°-2°)
Top diameter (mm) 200 200 200 200 200 200
Butt diameter (mm) 345 370 395 415 435 455
Thickness (mm) 6 6 6 6 6 6
E (2°-15°)
Top diameter (mm) 200 200 200 200 200 200
Butt diameter (mm) 545 585 625 660 700 740
Thickness (mm) 6 6 6 6 6 6
C (15°-30°)
Top diameter (mm) 250 250 250 250 250 250
Butt diameter (mm) 600 645 690 730 770 805
Thickness (mm) 6 6 6 6 6 6
D (30°-90°)
Top diameter (mm) 300 300 300 300 300 300
Butt diameter (mm) 680 730 725 765 755 790
Thickness (mm) 6 6 7 7 8 8
Material Description
  • Poles are made by high-quality metal plants, molded into multi-row cone-shaped vertical steel bars with hot galvanized anti-corrosion treatment
  • Light plate frame is made of high-quality stainless steel
  • Fastened with stainless steel bolts and nuts
Gr65 Material Steel Power Pole with 460 MPa Yield Strength and 620 MPa Tensile Strength for High Voltage Transmission 0
Our Services
1. Reply to your inquiry within 24 working hours
2. Experienced staff answer all questions in fluent English
3. Customized designs available (UEM&UBM welcomed)
4. Exclusive solutions provided by professional engineers
5. Special discounts and sales protection for distributors
6. Professional manufacturer with 20+ years experience in steel pole production
7. Samples available for testing (shipping charges may apply)
8. Superior raw materials and advanced manufacturing processes ensure high quality
Gr65 Material Steel Power Pole with 460 MPa Yield Strength and 620 MPa Tensile Strength for High Voltage Transmission 1
Company Introduction
Jiangsu Milky Way Steel Poles, established in 1991 and located in Wuxi, China near Shanghai Port, specializes in manufacturing steel poles including transmission power poles, street light poles, and high mast poles.
With 24 years of experience, we have exported to over 70 countries including America, Australia, Russia, Germany, Spain, Philippines, Malaysia, and Africa.
Notable projects include supplying street light poles for Dubai Tower and high mast poles for the Sochi Winter Olympic Games.
