Hexagonal 5m Powder Coating Galvanized Steel Pole One Section with One Cross Arm

1 pcs
MOQ
Anlaşılabilir
fiyat
Hexagonal 5m Powder Coating Galvanized Steel Pole One Section with One Cross Arm
Özellikleri Fotoğraf Galerisi Ürün Açıklaması Fiyat talebi
Özellikleri
Teknik Özellikler
Product Name: Galvanized Steel Pole
Wind Speed: 30m/s
Welding standard: AWS D 1.1 /BS EN 1011-1,BS EN 1011-2
Design: Customized
Material: Q345
Lift time: 50 years
Warranty: 15 years
Vurgulamak:

galvanised steel poles

,

power line pole

Temel bilgiler
Place of Origin: China
Marka adı: MilkyWay
Sertifika: ISO9001/BV/
Model Number: Galvanized Steel Pole
Ödeme & teslimat koşulları
Packaging Details: As customer request
Delivery Time: 20 working days after received your payment
Payment Terms: T/T, L/C at sight
Supply Ability: 300pcs per day
Ürün Açıklaması

 Hexagonal 5m Powder Coating Galvanized Steel Pole One Section with One Cross Arm





 Description:

 We Are Manufacturer of high quality Seamless Steel Pipe Seamless Steel Pipe type including single and  double arms, round ,hexagonal and octagonal type, about the thickness and height we can do as specifc  demands.



 Specifications:



Height

From 6 m to 15 m

Suit for

Airport ,seaport,plaza,stadium ,square,highway,
street way etc

Shape

Conoid ,Multi-pyramidal,Columniform,polygonal or conical

Material

Usually Q345B/A572,minimum yield strength>=345n/mm2
              Q235B/A36,minimum yield strength>=235n/mm2
As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400,
SS490, to ST52-

Lamp power

20 W- 400 W (HPS/MH)
220V (+-10%) /50Hz

Torlance of the dimenstion

+- 2%

Optical assembly of lighting fixture

IP 65

Electroshock resistant protective grade

Grade  Ⅰ

The casing anti-corrosion performance

Class Ⅱ

Working atmosphere of lighting fixture

-35 ℃~+45 ℃

Surface treatment

Hot dip galvanized Following ASTM A 123,
color polyester power or any other standard by client required.

Joint of Poles

Insert mode,innerflange mode,face to face joint mode

Design of pole

Against earthquake of 8 grade

Wind Speed

160 Km/Hour

Minimum yield strength

355 mpa

Minimum ultimate tensile strength

490 mpa

Max ultimate tensile strength

620 mpa

Standard

ISO 9001

Length of per section

Within 14m once forming without slip joint

Welding

We has past flaw testing.Internal and external double welding makes
the welding beautiful in shape
Welding Standard :AWS ( American Welding Society ) D 1.1

Thickness

1 mm to 30 mm

Style

Size and styles are veriable as per customer request





 Design:We have our standard pole with our design,OEM and ODM is also accpetable

 Hexagonal 5m Powder Coating Galvanized Steel Pole One Section with One Cross Arm 0

 Packages:Standard seaworthy

 Hexagonal 5m Powder Coating Galvanized Steel Pole One Section with One Cross Arm 1







 Application:
 Highway Seamless Steel Pipe                                Park Seamless Steel Pipe
 Main Roads Seamless Steel Pipe                         Dock Seamless Steel Pipe
 Secondary Roads Seamless Steel Pipe              Stadium Seamless Steel Pipe
 Storage-yar Seamless Steel Pipe                         Overpass Seamless Steel Pipe
 Industrial-Plant Seamless Steel                            Toll-Station Seamless Steel Pipe



 Hexagonal 5m Powder Coating Galvanized Steel Pole One Section with One Cross Arm 2



 Company Introduction:

 JiangSu Milky Way Steel Poles Co., Ltd.was established in 1988, is located in Yixing City, Jiangsu  Province, Wan Shi Town, covering an area of 35,000 square meters, annual output value reached 200  million . We have 20 years experience in design and  production. Our main products are power pole,  communication towers, street lighting poles, steel bracket and so on. The company has strong technical  force, advanced production equipment, perfect quality management system, product quality has reached  international advanced level.
