Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV

Büyük resim : Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV

Ürün ayrıntıları:

Menşe yeri:	Çin
Marka adı:	MilkyWay
Sertifika:	ISO9001/BV/
Model numarası:	Şanzıman Çelik Güç Direği

Ödeme & teslimat koşulları:

Min sipariş miktarı:	1 adet
Fiyat:	Anlaşılabilir
Ambalaj bilgileri:	Müşteri isteği olarak
Teslim süresi:	Ödemenizi aldıktan sonra 20 iş günü
Ödeme koşulları:	T/T, L/C Sight
Yetenek temini:	günde 300 adet

İletişim

Detaylı ürün tanımı

Ürün adı:	Galvanizli Güç Direği	Şekil:	sekizgen veya yuvarlak
Güç kapasitesi:	10kV - 220kV	Direklerin Ortak:	Kayar Derz
Garanti süresi:	15 yıl	Kalınlık:	1 mm ila 36 mm
Vurgulamak:	galvanized steel power transmission poles , 25ft-40ft power transmission poles , 10kV-220kV power transmission poles

Galvanized Steel Power Transmission Poles for Utility Lines

Available in 25ft, 30ft, 35ft, and 40ft lengths with competitive pricing

Product Specifications

Product Name	Galvanized Power Pole
Shape	Octagonal Or Round
Power Capacity	10kV to 220kV
Joint of Poles	Slip joint
Warranty time	15 years
Thickness	1 mm to 36mm

Steel Material Quality

All materials are sourced from reputable mills to ensure quality. Each shipment includes a mill certificate with stamp and signature for verification before unloading.

Before production, all materials undergo rigorous chemical and physical analysis to confirm they meet required strength and composition standards.

Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV 0

Detailed Specifications

Types Length	45ft	50ft	55ft	60ft	65ft	70ft
13.75m	15.25m	16.80m	18.30m	19.85m	21.35m
B (0°-2°)
Top diameter (mm)	200	200	200	200	200	200
Butt diameter (mm)	345	370	395	415	435	455
Thickness (mm)	6	6	6	6	6	6

Manufacturing Tolerances

Component Length: -25mm to 75mm
Straightness: 2mm/m
Twisting degree: 1° per 3 meters length
Ovalisation: Maximum is 3%
The average diameter: +/-0.5%
Slip length: +/-150mm

Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV 1

Welding Standards

Our welding processes have passed flaw testing. We use internal and external double welding for both strength and aesthetic quality.

Welding Standard: AWS (American Welding Society) D 1.1

Galvanized Steel Power Transmission Poles 25ft-40ft 10kV-220kV 2

Surface Treatment

Hot dip galvanized following ASTM A 123 standards. Custom color polyester powder or other client-required finishes available.

Company Introduction

Jiangsu Milky Way Steel Poles, established in 1991 and located in Wuxi, China near Shanghai Port, has over 24 years of experience manufacturing steel poles including transmission power poles, street light poles, and high mast poles.

Since 1991, we've exported to over 70 countries worldwide including the USA, Australia, Russia, Germany, Spain, Philippines, Malaysia, and throughout Africa.

We've supplied major projects globally, including street light poles for Dubai Tower and high mast poles for the Sochi Winter Olympic Games.
