Single Arms Q235 Steel High Mast Street Lighting Poles Galvanized Street Light Pole

Sertifika
Çin Jiangsu milky way steel poles co.,ltd Sertifikalar
Çin Jiangsu milky way steel poles co.,ltd Sertifikalar
Dear Sirs, Hereby we confirm that JiangSu MilkyWay steel poles co., ltd is our partner for several years. Since that time this company has shown itself as reliable supplier of qualitative products.We also would like to note that they provide top level service and all kinds of support.We plan to continue our fruitful cooperation co-operation for many years more.

—— Abacus

We do hereby certify the 69 KV transmmision line steel pole(from 25ft to 90 ft ) manufacuterd by Jiangsu Milky Way Steel Poles Co., Ltd since 2010.We are satisfied with their quality,service and the ways and attention they showed toward our order.

—— National Electricity Company

Ben sohbet şimdi

Single Arms Q235 Steel High Mast Street Lighting Poles Galvanized Street Light Pole

Çin Single Arms Q235 Steel High Mast Street Lighting Poles Galvanized Street Light Pole Tedarikçi
Single Arms Q235 Steel High Mast Street Lighting Poles Galvanized Street Light Pole Tedarikçi Single Arms Q235 Steel High Mast Street Lighting Poles Galvanized Street Light Pole Tedarikçi Single Arms Q235 Steel High Mast Street Lighting Poles Galvanized Street Light Pole Tedarikçi Single Arms Q235 Steel High Mast Street Lighting Poles Galvanized Street Light Pole Tedarikçi

Büyük resim :  Single Arms Q235 Steel High Mast Street Lighting Poles Galvanized Street Light Pole

Ürün ayrıntıları:

Place of Origin: China,Jiangsu
Marka adı: MilkyWay
Sertifika: ISO9001/BV/
Model Number: Street Light Poles

Ödeme & teslimat koşulları:

Minimum Order Quantity: 1 pcs
Fiyat: Negotiation
Packaging Details: As customer request
Delivery Time: 20 working days after received your payment
Payment Terms: T/T, L/C at sight
Supply Ability: 300pcs per day
İletişim
Detaylı ürün tanımı
tolerance: +/-2% Product Name: 30ft Single Arms Q235 Steel High Mast Street Light Poles With Drawing
Pole finished: galvanized high mast pole Payment Terms:: T/T ,L/C
Surface treatment: Hot dip galvanized safty Facor: 1.8
Thickness: 3mm 4mm Customization Available
Vurgulamak:

street lighting poles

,

street lamp pole

30ft Single Arms Q235 Steel High Mast Street Light Poles With Drawing





Specification:



name

30ft Single Arms Q235 Steel High Mast Street Light Poles With Drawing

Type

street light pole

Shape

conical, hexagonal and octagonal

Material

Usually   Q345B/A572,minimum yield strength>=345n/mm2
Q235B/A36,minimum yield strength>=235n/mm2
As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490ST52

Torlance of dimenstion

-0.02

Design Load in Kg

300~ 1000 Kg appliced to 50cm from the to pole

Surface treatment

Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.

Standard

Octagonal Conical tapered column
Certified by SIRIM QAS INTERNATIONAL.
Approved by JABATAN KERJA RAYA MALAYSIA.
Conforms to Standard:
Pole design : BS EN 40
Material : BS EN 10025 S275 / JIS G3101 SS400
Welding : BS 5135
Galvanizing : BS 729 / ISO 1461 ASTM A 123

Length of per section

Within 14m once forming without slip joint.

high mast pole suit for

city square,wharf,stadium

Option of high mast pole

Height from 20m to 35m
Flange mounted or planted type

Production Process of high mast pole

Raw material test  Cutting Molding or bending Welidng (longitudinal )Dimension verify Flange welding Hole drilling Calibration DeburrGalvanization or powder coating ,painting RecalibrationThread Packages



Single Arms Q235 Steel High Mast Street Lighting Poles Galvanized Street Light Pole 0





·Material :SS400, Q235,A36 (yield strength: 235Pa 24kg/mm2 Tensile Strength: 375-460Pa 38-47kg/mm2

(Other Material is Available on Request)

·Hot Dip Galvanized (≥86um)

·Any Color Polyester Powder Coated (≥100 um)

·Taper Conical , Octagonal, Polygon Section

·With demounted bracket design,easy loaded,install,and maintenance

·Theftproof slide lock

·Category: Street lighting pole, Garden Lighting pole Solar Street lighting pole, High Mast,highmast light poles,





Single Arms Q235 Steel High Mast Street Lighting Poles Galvanized Street Light Pole 1

Single Arms Q235 Steel High Mast Street Lighting Poles Galvanized Street Light Pole 2

1. Prices conditions

Price can be FOB, CIF ,EXW, or With taxes.


2. What will be the delivery time and what will be the mode of payment?
We have large quantities in Stock for normal color,Normal size ,for special color and products sizes it need to 3-5 days to customize.
50K units is available for most of our models in normal color and sizes
The payment can be T/T transaction,Letter of credit,Paypal,Western Union.


3. Shipment will be over sea or by air?
Generally speaking ,we ship the products by DHL UPS FEDEX express since the products isn’t too heavy for the transportation,
and oversea for led lights,and can be customized by your requirements.


4. Could you please send me the sample for the same. So that i could see and analyze its quality?
Yes. We can send samples first, samples need to be charged if the value is higher.


5. Will there be any contract for this business or trade?
Yes, there is a normal contract before the order is placed.
