School / Villas Steel High Mast Street Lamp Pole With Drawing 30 ft Height

Sertifika
Çin Jiangsu milky way steel poles co.,ltd Sertifikalar
Çin Jiangsu milky way steel poles co.,ltd Sertifikalar
Dear Sirs, Hereby we confirm that JiangSu MilkyWay steel poles co., ltd is our partner for several years. Since that time this company has shown itself as reliable supplier of qualitative products.We also would like to note that they provide top level service and all kinds of support.We plan to continue our fruitful cooperation co-operation for many years more.

—— Abacus

We do hereby certify the 69 KV transmmision line steel pole(from 25ft to 90 ft ) manufacuterd by Jiangsu Milky Way Steel Poles Co., Ltd since 2010.We are satisfied with their quality,service and the ways and attention they showed toward our order.

—— National Electricity Company

Ben sohbet şimdi

School / Villas Steel High Mast Street Lamp Pole With Drawing 30 ft Height

Çin School / Villas Steel High Mast Street Lamp Pole With Drawing 30 ft Height Tedarikçi
School / Villas Steel High Mast Street Lamp Pole With Drawing 30 ft Height Tedarikçi School / Villas Steel High Mast Street Lamp Pole With Drawing 30 ft Height Tedarikçi School / Villas Steel High Mast Street Lamp Pole With Drawing 30 ft Height Tedarikçi School / Villas Steel High Mast Street Lamp Pole With Drawing 30 ft Height Tedarikçi

Büyük resim :  School / Villas Steel High Mast Street Lamp Pole With Drawing 30 ft Height

Ürün ayrıntıları:

Place of Origin: China,Jiangsu
Marka adı: MilkyWay
Sertifika: ISO9001/BV/
Model Number: Street Light Poles

Ödeme & teslimat koşulları:

Minimum Order Quantity: 1 pcs
Fiyat: Negotiation
Packaging Details: As customer request
Delivery Time: 20 working days after received your payment
Payment Terms: T/T, L/C at sight
Supply Ability: 300pcs per day
İletişim
Detaylı ürün tanımı
tolerance: +/-2% Product Name: 30ft height School / Villas Steel High Mast Street Light Poles With Drawing 1.0 Safety Factor
Pole finished: galvanized high mast pole Payment Terms:: T/T ,L/C
Supply Ability:: 2000pcs per week safty Facor: 1.8
Thickness: 3mm 4mm Customization Available
Vurgulamak:

street lamp pole

,

galvanized street light pole

30ft height School / Villas Steel High Mast Street Light Poles With Drawing 1.0 Safety Factor





Specification:



name

30ft height School / Villas Steel High Mast Street Light Poles With Drawing 1.0 Safety Factor

Type

street light pole

Shape

conical, hexagonal and octagonal

Material

Usually   Q345B/A572,minimum yield strength>=345n/mm2
Q235B/A36,minimum yield strength>=235n/mm2
As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490ST52

Torlance of dimenstion

-0.02

Design Load in Kg

300~ 1000 Kg appliced to 50cm from the to pole

Surface treatment

Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.

Standard

Octagonal Conical tapered column
Certified by SIRIM QAS INTERNATIONAL.
Approved by JABATAN KERJA RAYA MALAYSIA.
Conforms to Standard:
Pole design : BS EN 40
Material : BS EN 10025 S275 / JIS G3101 SS400
Welding : BS 5135
Galvanizing : BS 729 / ISO 1461 ASTM A 123

Length of per section

Within 14m once forming without slip joint.

high mast pole suit for

city square,wharf,stadium

Option of high mast pole

Height from 20m to 35m
Flange mounted or planted type

Production Process of high mast pole

Raw material test  Cutting Molding or bending Welidng (longitudinal )Dimension verify Flange welding Hole drilling Calibration DeburrGalvanization or powder coating ,painting RecalibrationThread Packages



School / Villas Steel High Mast Street Lamp Pole With Drawing 30 ft Height 0





·Material :SS400, Q235,A36 (yield strength: 235Pa 24kg/mm2 Tensile Strength: 375-460Pa 38-47kg/mm2

(Other Material is Available on Request)

·Hot Dip Galvanized (≥86um)

·Any Color Polyester Powder Coated (≥100 um)

·Taper Conical , Octagonal, Polygon Section

·With demounted bracket design,easy loaded,install,and maintenance

·Theftproof slide lock

·Category: Street lighting pole, Garden Lighting pole Solar Street lighting pole, High Mast,highmast light poles,





School / Villas Steel High Mast Street Lamp Pole With Drawing 30 ft Height 1

School / Villas Steel High Mast Street Lamp Pole With Drawing 30 ft Height 2

1. Prices conditions

Price can be FOB, CIF ,EXW, or With taxes.


2. What will be the delivery time and what will be the mode of payment?
We have large quantities in Stock for normal color,Normal size ,for special color and products sizes it need to 3-5 days to customize.
50K units is available for most of our models in normal color and sizes
The payment can be T/T transaction,Letter of credit,Paypal,Western Union.


3. Shipment will be over sea or by air?
Generally speaking ,we ship the products by DHL UPS FEDEX express since the products isn’t too heavy for the transportation,
and oversea for led lights,and can be customized by your requirements.


4. Could you please send me the sample for the same. So that i could see and analyze its quality?
Yes. We can send samples first, samples need to be charged if the value is higher.


5. Will there be any contract for this business or trade?
Yes, there is a normal contract before the order is placed.



Company:



Estbilsed in 1989,Jiangsu Milky Way Steel Poles is located in Wuxi,East of China ,near one of the largest sea port of China ,Shanghai,Port .

Our Products have been widely used in the power transmsion ,signal transmission and ligting for street ,road ,square ,palaestra.and so on

We have plenty of export experience . Since our first overseas order from Pakstan in 1991 of 132 KV transmission poels ,our products have been deliveried to more than 70 contries and areas ,including America,Australia ,Russia ,Genmery ,Span,Philippines ,Malaysia and so on
