Round 20M 12KN Steel Utility Pole for Electrical Power Transmission with Cross Arm

Büyük resim : Round 20M 12KN Steel Utility Pole for Electrical Power Transmission with Cross Arm

Ürün ayrıntıları:

Place of Origin:	China
Marka adı:	MilkyWay
Sertifika:	ISO9001/BV/
Model Number:	Steel Utility Pole

Ödeme & teslimat koşulları:

Minimum Order Quantity:	1 pcs
Fiyat:	Negotiation
Packaging Details:	As customer request
Delivery Time:	20 working days after received your payment
Payment Terms:	T/T, L/C at sight
Supply Ability:	300pcs per day

İletişim

Detaylı ürün tanımı

Product Name:	Steel Utility Pole	Application:	Electricity distribution
Galvanization Thickness:	Average 86μm	Standard:	ISO
Design:	Customized	Welding standard:	AWS D 1.1
Warranty:	15 years
Vurgulamak:	electrical utility poles , electric telescoping pole

Round 20M 12KN Steel Utility Pole for Electrical Power Transmission with Cross Arm

Specifications:

Suit for	Electricity distribution
Shape	Conoid ,Multi-pyramidal,Columniform,polygonal or conical
Joint of Poles	Insert mode,innerflange mode,face to face joint mode
Design of pole	Against earthquake of 8 grade
Wind Speed	160 Km/Hour . 30 m /s
Standard	ISO 9001
Length of per section	Within 14m once forming without slip joint
Welding	We has past flaw testing.Internal and external double welding makes the welding beautiful in shape Welding Standard :AWS ( American Welding Society ) D 1.1
Thickness	1 mm to 30 mm
Production Process	Rew material test → Cuttingj →Molding or bending → Welidng (longitudinal )→Dimension verify →Flange welding →Hole drilling →Calibration → Deburr→Galvanization or powder coating ,painting →Recalibration →Thread →Packages
Packages	Our poles as normal cover by Mat or straw bale at the top and bottom , anyway also can following by client required , each 40HC or OT can loading how many pcs will calculation base on the client actually specification and data.

Steel
The material is in accordance with NF EN 10025
Standard and NF EN 10149 Standard,it has the following property.
-Yield Strength=355N/mm2
-Toughness remains the same under 20 degrees below zero.
-Galvanization is in accordance with NFA35503 Standard Class 1.

Round 20M 12KN Steel Utility Pole for Electrical Power Transmission with Cross Arm 0

Design:

We have our standard pole with our design, OEM and ODM is also accpetable

Round 20M 12KN Steel Utility Pole for Electrical Power Transmission with Cross Arm 1

Company Introduction:

Our development is based on quality, which allows us to always be able to stand ahead of the industry. In 1995, because of the introduction of the ISO9001 quality management system, our product quality has been further increased and guaranteed. We have advanced testing equipment and experienced technical engineers. This gives us continuously improve product quality to meet customer needs. Based on product characteristics, we divide the inspection into four phases: raw materials inspection, production process inspection, finished product inspection and regular inspection. Ours Qc have been engaged in quality work for a long time and they consists of our quality deapartment . We implement the ISO9001 completely in during the process of productiong , proposed a concept. " the best way to return customers is to provide high-quality product" !

Round 20M 12KN Steel Utility Pole for Electrical Power Transmission with Cross Arm 2
