Hot Dip Galvanized 132kv 10m Electrical Power Pole for Electrical Transmission

Büyük resim : Hot Dip Galvanized 132kv 10m Electrical Power Pole for Electrical Transmission

Ürün ayrıntıları:

Place of Origin:	China
Marka adı:	Milky Way
Sertifika:	ISO//BV
Model Number:	Hot Dip Galvanized 132kv 10m Electrical Power Pole for Electrical Transmission

Ödeme & teslimat koşulları:

Minimum Order Quantity:	one 40HQ
Fiyat:	negotiation
Packaging Details:	as per customer request
Delivery Time:	usually 2 weeks after confirming
Payment Terms:	T/T
Supply Ability:	300 pieces pole per day

İletişim

Detaylı ürün tanımı

Style:	hot dip galvanized	Wind speed:	160km/h,30m/s
Thickness:	1mm to 30mm	Tolance of dimenstion:	+-2%
Shape:	conoid ,multi-pyramidal,columniform，polygonal or conical	Design of pole:	against earthquake of 8 grade
Vurgulamak:	electric power pole , transmission line poles

Hot Dip Galvanized 132kv 10m Electrical Power Pole for Electrical Transmission

Specifications

Type	Straight Pole ,Tensile Pole ,Turn Pole
Suit for	Electricity distribution
Shape	Conoid ,Multi-pyramidal,Columniform,polygonal or conical
Material	Usually Q345B/A572,minimum yield strength>=345n/mm2 Q235B/A36,minimum yield strength>=235n/mm2 As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, to ST52-
Torlance of dimenstion	+- 2%
Power	10 KV ~550 KV
Safety Factor	Safety factor for conducting wine : 8 Safety factor for grounding wine : 8
Design Load in Kg	300~ 1000 Kg appliced to 50cm from the to pole
Marks	Nane palte through rivert or glue ,engrave ,emboss as per customer requirement
Surface treatment	Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
Joint of Poles	Insert mode,innerflange mode,face to face joint mode .
Design of pole	Against earthquake of 8 grade
Wind Speed	160 Km/Hour . 30 m /s
Minimum yield strength	355 mpa
Minimum ultimate tensile strength	490 mpa
Max ultimate tensile strength	620 mpa
Standard	ISO 9001
Length of per section	Within 14m once forming without slip joint
Welding	We has past flaw testing.Internal and external double welding makes the welding beautiful in shape Welding Standard :AWS ( American Welding Society ) D 1.1
Thickness	1 mm to 30 mm
Production Process	Rew material test → Cuttingj →Molding or bending →Welidng (longitudinal ) →Dimension verify →Flange welding →Hole drilling →Calibration → Deburr →Galvanization or powder coating ,painting →Recalibration →Thread →Packages
Packages	Our poles as normal cover by Mat or straw bale at the top and bottom , anyway also can following by client required , each 40HC or OT can loading how many pcs will calculation base on the client actually specification and data.

Hot Dip Galvanized 132kv 10m Electrical Power Pole for Electrical Transmission 0

Our Service

1. Factory direct sale.
2. Industry and trade integration business.
3. 15 years experience.
4. Customized designs.
5. ODM, OEM acceptable.
6. Flexible payment.
7. Fast, accurate quotes.
8. Our good service.
9. Technical support by e-mail.
10. Calling service.
11. Provide maintenance instruction video.

Advantages

1) Higher quality lower cost to win the competitive price.
2) Less land occupation
3) Warranty of quality: More than 25 years.
4) 3 production lines to ensure fast delivery date.
5) OEM, ODM service.
6) Skilled manufacturer, quality control and technical team.
7)Great anti-corrosion performance
8)Dual protection treatments: hot galvanized first and then powder paint

Hot Dip Galvanized 132kv 10m Electrical Power Pole for Electrical Transmission 1

FAQ

Q1. How can I get a price of needed pole?
A: 1. Please give the exactly dimensions such as height, thickness, material, top and bottom dia. We can give you a similar price according to your specification.
2. You can send us a drawing; we can give you a price according to your drawing.
Q2. I am a small wholesaler, do you accept small order?
A: It's no problem if you are a small wholesaler; we would like to grow up with you together.
Q3. I am a designer; Can you help me to produce the sample which we designed?
A: Our mission is to help customers to be successful. So it's welcome if we can help you solve problem and make your design come true.
Q4. We want be your agent of our area. How to apply for this?
A: Please send your idea and your profile to Sino-Gsl.
Q5. Can you make Door to Door service? Because i don't know how to do customs clearance.
A:Yes. We can make Door to Door service to help you save much time of shipping. Also we have big discount with shipping company because we have do much of this every day. So it will save your time and money.

Hot Dip Galvanized 132kv 10m Electrical Power Pole for Electrical Transmission 2
